Home » Carbon Round Adjustable Die, 5/16-18 UNC, 1.5 in OD
Greenfield Threading

Carbon Round Adjustable Die, 5/16-18 UNC, 1.5 in OD

SKU: A00170120 Barcode: 697334224110
In stock

Payment details

  • American Express
  • Discover
  • Mastercard
  • Visa
  • Brand Greenfield Threading
  • SKU A00170120
  • Barcode 697334224110
  • Unit of Measurement Each
  • Package Quantity 1 EA = 1 EA
  • Country of Origin US
  • Manufacture Part # 402241

Features

  • Use in hand-held die stocks or machine holders
  • Chamfered on both faces, 2 to 3 threads on one side and 1 to 2-1/2 threads on the other for threading close to the shoulder
  • Beveled screw slot to remove screw when die is used in a machine holder

Specifications

  • Applicable Materials: All Metals
  • Cutting Direction: Right
  • Material: Carbon Steel
  • Outside Diam [Nom]: 1.5 in
  • Shank Size Symbol: 5/16-18 UNC
  • Style: Round Adjustable Die
  • Thread Size [Nom]: 5/16 in
  • Thread Standard: 0.3125 in
  • Threads Per Inch [Nom]: 18
  • Type: Die
