Single-Stage Preset Regulator, Medical Air, 0 to 50 psi, 3000 psi Inlet, CGA 346 Nut and Nipple

SKU: A00130193 Barcode: 698944027995
In stock

Payment details

  • American Express
  • Discover
  • Mastercard
  • Visa
  • Brand Western Enterprises
  • SKU A00130193
  • Barcode 698944027995
  • Unit of Measurement Each
  • Package Quantity 1 EA = 1 EA
  • Country of Origin US
  • Manufacture Part # M1346P

Features

  • Chrome-plated brass body with all brass high-pressure chamber
  • Internal reseating relief valve protects against over-pressurization
  • Sintered filter for additional safety and to extend regulator life
  • Available with horizontal outlet (M1A) or with 90 outlet (M1)

Specifications

  • Diaphragm Material: Neoprene
  • Flow Range: 0 to 50 psi
  • Gas Type: Medical Air
  • Gauge Size: 2 in
  • Inlet Connection: CGA 346 Nut and Nipple
  • Inlet Pressure [Max]: 3000 psi
  • Outlet Pressure [Max]: 50 psi
  • Type: Preset with 90 Outlet
